The Newin 320KF is a 13-inch tabletop fully automatic frozen meat slicer designed for commercial meat preparation. It uses a 320mm slicing blade and a dual-motor configuration with a rated input power of 550W + 550W.
The 320KF features a full stainless steel body, adjustable slicing thickness and a fully automatic operating configuration. Its specified mutton cutting size is 2 × Ø120mm, with a rectangular cutting size of 200 × 140mm.
With a 60kg net weight and a tabletop-format machine design, the 320KF is suitable for businesses looking for a larger commercial meat slicer while keeping the machine within a relatively compact equipment format. It can be considered for hot pot restaurants, butcher shops, supermarket meat counters, catering kitchens and other commercial meat preparation applications.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | 320KF |
| Machine Type | 13-Inch Tabletop Fully Automatic Frozen Meat Slicer |
| Blade Diameter | 320mm / 13 inch |
| Mutton Cutting Size | 2 × Ø120mm |
| Rectangular Cutting Size | 200 × 140mm |
| Rated Input Power | 550W + 550W |
| Motor Configuration | Dual Motor |
| Rated Voltage | 220–240V |
| Rated Frequency | 50Hz |
| Net Weight | 60kg |
| Machine Dimensions | 640 × 660 × 680mm |
| Package Dimensions | 750 × 750 × 740mm |
| Waterproof Rating | IPX1 |
320mm / 13-Inch Slicing Blade
The 320KF uses a 320mm diameter slicing blade, giving it a 13-inch slicing format for commercial meat preparation. The larger blade format can be considered by businesses that need to process larger meat products than those suited to smaller commercial slicers.
The specified mutton cutting size is 2 × Ø120mm, while the rectangular cutting size is 200 × 140mm. These dimensions should be compared with the size and shape of the meat products used in your operation before selecting the machine.
For businesses comparing different frozen meat slicer sizes, the 300KR 12-inch automatic frozen meat slicer provides a smaller 300mm blade format.
Tabletop Fully Automatic Design
The 320KF is designed as a tabletop fully automatic frozen meat slicer. Its automatic operating configuration is intended for commercial users who need a powered slicing process rather than manual or semi-automatic operation.
The tabletop format is useful for businesses that need a 13-inch slicing machine but want to keep the equipment within a defined working area. Before installation, buyers should check the machine dimensions, working space and access requirements of the intended location.
Dual 550W Motor Configuration
The 320KF uses two motors with a rated input power of 550W + 550W. The dual-motor configuration is part of the machine’s automatic operating system.
For commercial equipment buyers, the motor configuration is an important specification when comparing different automatic meat slicers and checking the electrical requirements for installation.
The rated electrical specification is 220–240V at 50Hz. Confirm the available power supply at the installation site before ordering.
Adjustable Slicing Thickness
The 320KF is designed with adjustable slicing thickness, allowing operators to select the required slice thickness according to the meat product and preparation requirements.
The specific thickness setting should be selected according to the characteristics of the meat being processed and the operating instructions supplied with the machine.
Full Stainless Steel Body
The 320KF features a full stainless steel body for commercial food preparation environments. The stainless steel construction provides a practical surface for routine cleaning and maintenance around the meat preparation area.
Operators should remove meat residue from accessible surfaces and the cutting area after use, then clean and dry the machine according to the supplied operating instructions.
Frozen Meat and Mutton Cutting
The 320KF is positioned for frozen meat slicing applications and is suitable for commercial preparation where frozen meat products need to be portioned into slices.
The specified mutton cutting size is 2 × Ø120mm. Buyers should check the dimensions and condition of their frozen meat products before ordering to ensure they are suitable for the machine’s cutting configuration.
The 320KF is particularly relevant to commercial kitchens and meat preparation businesses that regularly handle mutton and other frozen meat products.
Suitable Applications
The Newin 320KF can be considered for a range of commercial frozen meat preparation applications, including:
- Hot pot restaurants and kitchens
- Butcher shops and meat counters
- Supermarket meat departments
- Restaurant and hotel kitchens
- Catering and central kitchens
- Commercial mutton preparation
- Frozen meat preparation operations
The appropriate application depends on the type and dimensions of the meat products, required slicing format, operating conditions and available electrical supply.
Choosing the 320KF for Your Application
The 320KF is a suitable model to consider when a business needs a 13-inch tabletop fully automatic frozen meat slicer with a 320mm blade and dual 550W motors.
When comparing commercial frozen meat slicers, buyers should consider blade diameter, machine format, cutting size, motor configuration, machine dimensions and electrical requirements.
For a smaller 12-inch automatic frozen meat slicer, the 300KR 12-inch automatic frozen meat slicer uses a 300mm blade and has a 55kg net weight.
For a 13-inch commercial electric meat slicer intended for a different product positioning, the 320KR 13-inch commercial electric meat slicer is another model to compare.
For a 13-inch automatic frozen beef slicing application, the 320KRS 13-inch automatic frozen beef slicer uses a 320mm blade with a 66kg net weight.
Installation and Power Supply
Before installation, place the 320KF on a stable and suitable working surface with enough surrounding space for operation, cleaning and routine maintenance.
The machine is rated for 220–240V at 50Hz, with a rated input power of 550W + 550W. Confirm that the electrical supply at the installation site matches the machine specification before operation.
The machine dimensions are 640 × 660 × 680mm. Check the available installation space and access route before ordering, particularly when the machine will be installed in a commercial kitchen or meat preparation area.
The package dimensions are 750 × 750 × 740mm and can be used as a reference when planning transportation, receiving and installation.
🛠️ Maintenance Tips
- Clean meat residue from the cutting area after each use.
- Clean and dry the cutting components after washing.
- Check the knife condition regularly and maintain or replace the cutting components when necessary.
- Keep the machine surface and working area clean after operation.
- Follow the supplied operating and maintenance instructions for lubrication and component replacement.
Frequently Asked Technical Questions
Q: What size blade does the Newin 320KF use?
A: The 320KF uses a 320mm (13-inch) slicing blade.
Q: Is the 320KF a fully automatic frozen meat slicer?
A: Yes. The 320KF is a 13-inch tabletop fully automatic frozen meat slicer designed for commercial meat preparation.
Q: What is the motor configuration of the 320KF?
A: The 320KF uses a dual-motor configuration with a rated input power of 550W + 550W.
Q: What is the mutton cutting size of the 320KF?
A: The specified mutton cutting size is 2 × Ø120mm.
Q: What is the rectangular cutting size of the 320KF?
A: The specified rectangular cutting size is 200 × 140mm.
Q: What power supply does the 320KF require?
A: The specified power supply is 220–240V at 50Hz. The rated input power is 550W + 550W.
Q: What are the dimensions and weight of the 320KF?
A: The machine dimensions are 640 × 660 × 680mm and the net weight is 60kg. The package dimensions are 750 × 750 × 740mm.
Q: Does the 320KF have adjustable slicing thickness?
A: Yes. The 320KF is designed with adjustable slicing thickness so operators can select the required thickness according to the application.
Q: What is the waterproof rating of the 320KF?
A: The specified waterproof rating is IPX1. This rating should not be interpreted as permission to pressure-wash or fully immerse the machine.
Related Frozen Meat Slicers
Newin offers frozen meat slicers in different blade sizes and machine configurations. The following models can be compared with the 320KF according to application and equipment format:
- Commercial frozen meat slicers – browse the Newin meat slicer range.
- 300KR 12-inch automatic frozen meat slicer – a smaller 300mm automatic model.
- 320KR 13-inch commercial electric meat slicer – a 320mm commercial model with a different operating positioning.
- 320KRS 13-inch automatic frozen beef slicer – a 320mm automatic model focused on frozen beef slicing applications.
Request a Quote
If you are looking for a 13-inch tabletop fully automatic frozen meat slicer, the Newin 320KF can be evaluated according to your meat type, product dimensions, required cutting format and electrical supply.
For wholesale, distributor or commercial equipment inquiries, please provide the required quantity, destination country, voltage requirements and intended application when requesting a quotation. This information helps confirm the appropriate machine configuration and shipping requirements.
